Hello everyone, I am the Information Guy~
Today, I will introduce the intricacies of the const keyword and pointers in the C language. As we all know, the flexibility of pointers is the core charm of C, but it is also a double-edged sword—any slight misstep can lead to memory overflow, data corruption, and other issues.
The addition of the <span><span>const</span></span> keyword gives pointers the ability of “selective freedom”: it retains the dynamic operation of pointers while precisely controlling the modifiability of data. Today, we will reveal the core techniques of combining <span><span>const</span></span> with pointers based on practical engineering scenarios, helping you write safer and more robust code.
1. Technical Essence: Three “Contracts” of const and Pointers
Before diving into applications, let’s clarify the three combinations of <span>const</span> when modifying pointers (using the <span>int</span> type as an example):
| Syntax | Pointer Mutability | Content Mutability | Core Meaning |
|---|---|---|---|
<span>const int *p</span> |
✔️ | ❌ | Read-only data, pointer is flexible |
<span>int *const p</span> |
❌ | ✔️ | Fixed address, data can be modified |
<span>const int *const p</span> |
❌ | ❌ | Completely read-only |
Memory Mnemonic:•<span><span>const</span></span> on the left (<span><span>const T *p</span></span><code><span><span>) → Data is immutable</span></span>
•<span><span>const</span></span> on the right (<span><span>T *const p</span></span><code><span><span>) → Pointer is immutable</span></span>
• Both sides have <span><span>const</span></span> → Double lock seal
2. Practical Scenarios: Five Highlights of const Pointers
Function Parameters: A Tool for Defensive ProgrammingScenario: Designing a function to print the length of a string, ensuring that the internal content of the string will not be modified.
size_t safe_strlen(const char *str) {
// str[0] = 'A'; // Compilation error! Modification of data is prohibited
size_t len = 0;
while (str[len] != '\0') len++;
return len;
}
Value:• Clearly defines the function’s responsibility: <span>const char *</span> informs the caller that “this function will not modify your data.”
• Prevents internal misoperations: even if the function has complex logic, it cannot modify data through pointers.
Accessing Hardware Registers: A Mandatory Constraint on Address ImmutabilityScenario: Operating the registers of embedded devices, requiring fixed pointer addresses but allowing data to be written.
#define HW_REG_ADDR 0x40000000
volatile uint32_t *const reg = (uint32_t *)HW_REG_ADDR;
void set_register() {
*reg = 0x55AA; // Correct: write data
// reg = (void*)0x50000000; // Compilation error! Address is immutable
}
Value:• Prevents the pointer from being accidentally modified, ensuring the absolute correctness of hardware operation addresses.
• The combination of <span>volatile</span> and <span>const</span> ensures that the address is fixed while avoiding compiler optimizations.
Embedded Configuration Tables: Double Protection for Sensitive DataScenario: Read-only configuration parameters for storage devices (such as baud rate, parity).
const struct UartConfig {
int baud_rate;
char parity;
} *const config_table = (const struct UartConfig*)0x8000;
void init_uart() {
// config_table->baud_rate = 115200; // Error: data cannot be modified
// config_table = NULL; // Error: pointer cannot be modified
set_uart(config_table->baud_rate, config_table->parity);
}
Value:• Both data and pointer are <span>const</span>, preventing accidental overwriting of the configuration table at runtime.
• Mapped to a fixed memory address, suitable for configuration data stored in ROM or Flash.
Dynamic Memory Management: Preventing Pointer “Drift”Scenario: Allocating fixed blocks in a memory pool, ensuring that management pointers do not go out of bounds.
uint8_t memory_pool[1024];
uint8_t *const pool_start = memory_pool;
uint8_t *const pool_end = memory_pool + sizeof(memory_pool);
void* allocate_mem(size_t size) {
static uint8_t *current = memory_pool;
if (current + size > pool_end) return NULL;
void *ptr = current;
current += size;
return ptr;
}
Value:• <span>pool_start</span> and <span>pool_end</span> act as boundary sentinels, prohibiting modification and ensuring the memory pool range remains constant.
String Constants: Avoiding Wild Pointer TrapsScenario: Defining read-only global string constants.
const char *const LOG_HEADER = "[SYSTEM]: ";
void log_message(const char *msg) {
printf("%s%s\n", LOG_HEADER, msg);
// LOG_HEADER[0] = '('; // Error: data cannot be modified
// LOG_HEADER = "[ERROR]: "; // Error: pointer cannot be modified
}
Value:• Prevents string constants from being accidentally modified (which could otherwise trigger segmentation faults).
3. Advanced Techniques: The Game of const and Type Casting
Breaking through const restrictions? Beware of UB!Question: Can you modify <span>const</span> data through other pointers?
const int a = 100;
int *p = (int*)&a;
*p = 200; // Undefined behavior (UB)! May crash or silently fail
Conclusion:• <span>const</span> is a “gentleman’s agreement” among developers; breaking it may lead to unpredictable consequences.
Passing const through Multi-level PointersRules: <span>const</span> modifications should follow the “right to left” binding principle:
const int **pp1; // pp1 is mutable, *pp1 is mutable, **pp1 is immutable
int *const *pp2; // pp2 is mutable, *pp2 is immutable, **pp2 is mutable
int **const pp3; // pp3 is immutable, *pp3 is mutable, **pp3 is mutable
Application: Gradually constraining mutability in complex data structures (such as linked lists, trees).
4. Conclusion: The Engineering Philosophy of const Pointers
- Safety First: By checking at compile time, runtime errors are eliminated at the bud stage.
- Code as Documentation:
<span>const</span>clearly conveys data usage permissions, reducing collaboration costs within teams. - Resource Contracts: In embedded and system-level development, const pointers are the “guardians” of hardware, memory, and data.
