The timer mode macro definitions of the Nuvoton NUC230 series involve core working modes, capture functions, and counting methods. Below is a detailed analysis (combined with register operations and practical application scenarios):

1. Basic Working Modes (Controlled by TIMER_TCSR_MODE_Pos)

1. One-Shot Mode

#define TIMER_ONESHOT_MODE (0UL << TIMER_TCSR_MODE_Pos)

• Principle: The timer automatically stops after counting down from the initial value to 0, and must be manually restarted to count again.
• Register Behavior:
• <span>TCMPR</span> (comparison value) triggers an interrupt when effective
• Sets the interrupt flag when counting reaches 0, while stopping the count
• Application Scenario: Precise single delay (e.g., executing an operation after debouncing a button)

  // Pseudo code example
  Timer_Start();          // Start the timer
  while(!Timer_Timeout);  // Wait for the one-time count to finish


2. Periodic Mode

#define TIMER_PERIODIC_MODE (1UL << TIMER_TCSR_MODE_Pos)

• Principle: The timer automatically reloads the initial value after counting down to 0, generating periodic interrupts in a loop.
• Register Behavior:
• When counting reaches 0:

1. Reload<span>TDR</span> (data register) value to the counter
2. Set the interrupt flag

// Configuration example (1ms interrupt)
TIMER0->TDR = 12000 - 1;  // Assuming 12MHz clock, 12000 counts = 1ms
TIMER0->TCSR |= TIMER_PERIODIC_MODE;

3. Toggle Mode

#define TIMER_TOGGLE_MODE (2UL << TIMER_TCSR_MODE_Pos)

• Principle: The timer automatically toggles the specified pin level when counting reaches 0 (must be configured as output mode).
• Hardware Behavior:
• When counting reaches 0:

1. Toggle<span>TEX</span> pin level
2. Reload the initial value to continue counting

// Generate 1kHz square wave (clock 12MHz)
TIMER0->TDR = 6000 - 1;  // Half cycle count (6000 ticks = 0.5ms)
GPIO_SetMode(PB, BIT0, GPIO_MODE_OUTPUT);  // Set PB0 as output
TIMER_EnableTogglePin(TIMER0, PB0);       // Bind pin

4. Continuous Mode

#define TIMER_CONTINUOUS_MODE (3UL << TIMER_TCSR_MODE_Pos)

• Principle: The counter runs freely (after counting down from the initial value to 0, it continues counting from the maximum value 0xFFFF).
• Key Features:
• Does not automatically reload the initial value
• Only triggers an interrupt when counting reaches 0
• Application Scenario: Long-term timing, event timestamp recording

  // Get microsecond-level timestamp
  uint32_t get_timestamp() {
    return 0xFFFF - TIMER0->TCR;  // Read current count value
  }


2. Capture Function Mode (Controlled by TIMER_TEXCON Register)

1. Capture Behavior Selection

#define TIMER_CAPTURE_FREE_COUNTING_MODE (0UL << TIMER_TEXCON_RSTCAPSEL_Pos)

• Free Capture: Records the current count value when an external trigger occurs (does not interfere with counter operation), suitable for measuring pulse intervals.

#define TIMER_CAPTURE_COUNTER_RESET_MODE (1UL << TIMER_TEXCON_RSTCAPSEL_Pos)

• Reset Capture: Resets the counter when capturing, suitable for measuring pulse widths (reset on falling edge + capture on rising edge).

  // Measure pulse width pseudo code
  configure_capture(TIMER_CAPTURE_COUNTER_RESET_MODE, FALLING_EDGE);
  while(!capture_ready);
  width = get_captured_value();  // Time from rising edge to falling edge


2. Capture Edge Selection

3. Counting Mode (Controlled by TIMER_TEXCON_TX_PHASE_Pos)

1. **External Signal Counting Method

#define TIMER_COUNTER_FALLING_EDGE (0UL << TIMER_TEXCON_TX_PHASE_Pos)

• Falling Edge Counting: The counter increments by 1 for each falling edge on the external pin (<span>TEX</span>).

#define TIMER_COUNTER_RISING_EDGE (1UL << TIMER_TEXCON_TX_PHASE_Pos)

• Rising Edge Counting: The counter increments by 1 for each rising edge on the external pin.

“

Application Scenario:

• Rotary encoder pulse counting
• Counting objects passing through a photoelectric sensor

// Encoder counting configuration
TIMER_Open(TIMER0, TIMER_CONTINUOUS_MODE);  // Continuous counting
TIMER_SET_COUNTER_SOURCE(TIMER0, TIMER_COUNTER_RISING_EDGE);  // Rising edge counting

4. Mode Combination Application Example

Scenario: Measuring the echo time of an ultrasonic module

// 1. Configure capture mode
TIMER_ConfigCaptureChannel(TIMER0,
    TIMER_CAPTURE_COUNTER_RESET_MODE |  // Reset counter on capture
    TIMER_CAPTURE_RISING_EDGE           // Trigger on rising edge
);

// 2. Send 10us trigger pulse (omitted)

// 3. Wait for echo
while(!TIMER_GetCaptureIntFlag(TIMER0));

// 4. Read time
uint32_t echo_time = TIMER_GetCaptureData(TIMER0);

Key Register Quick Reference

By reasonably combining these modes, complex functions such as precise timing, PWM output, and pulse measurement can be efficiently achieved, significantly reducing CPU load.
