After tinkering with the home network, it’s almost time to timeout. Here’s a simple article.
Test Results
CPU
The detailed entries come from the GPGPU testing section of AIDA64. Due to many peculiar issues in this section, and the big-little core scheduling being a major challenge, it needs to be discussed in detail.
-
Normal scheduling
-
Used in bare-metal order (big cores first, then little cores): Winserver2022, Workstation 17
-
Big cores first, then little cores, finally big cores with hyper-threading: PVE (the default scheduling in Linux, which I believe is the optimal solution in terms of performance)
-
Abnormal scheduling
-
Started with little cores: winserver2022 (should be equivalent to win10 21h2), very weak, and unable to bind cores. Win10 and win11 22h2 should not have this issue.
-
Random scheduling jumps: ESXi, unfortunately, version 8.0u1 has not resolved this issue. It seems VMware will not care about consumer-grade anymore.
It is clear that PVE’s compatibility and performance loss are exceptional. Moreover, it is worth noting that the performance of soft routing, which is strongly related to AES encryption and decryption speed, still incurs losses in virtual machines.
-
Due to the 6.2GHz clearly overheating, I later adjusted the voltage settings, and the scores for ESXi and PVE seem to be slightly lower.
-
Hyper-V has a problem where it prioritizes using little cores (reportedly, this issue does not exist in win11).
-
ESXi cannot recognize big core hyper-threading, and threads may actually be randomly scheduled to big and little cores. This time, CPUZ only took the big core scores, but R23 single-core scores are averaged across all cores since each core basically ran once.
-
When using big and little cores, PVE is incompatible with AIDA64. It should not be counted in the scores.
| Test Item | windows | Hyper-V | Workstation | ESXi | PVE |
|---|---|---|---|---|---|
| cpuz-Single | 1007.5 | 944.9 | 938.1 | 914.3 | 988.9 |
| cpuz-Multi | 17665.1 | 17177.3 | 17460.8 | 15486.1 | 16767.5 |
| R23-Single | 2442 | 2073 | 2320 | 1468 | 2347 |
| R23-Multi | 42262 | 40802 | 40624 | 35300 | 38718 |
| Single Float | 2552 | 2530 | 2527 | 2573 | 134.1 |
| Double Float | 1276 | 1264 | 1254 | 1282 | 92.64 |
| 24bit Int | 937.8 | 939.9 | 933.8 | 917.5 | 69.23 |
| 32bit Int | 936.3 | 938.7 | 940.9 | 917.3 | 69.83 |
| 64bit Int | 311.6 | 293.3 | 290.1 | 295.0 | 21.48 |
| AES-256 | 308957 | 60233 | 170786 | 142080 | 7875 |
| SHA-1 | 79797 | 54958 | 63531 | 56031 | 3923 |
| Julia | 951.8 | 937.9 | 878.4 | 856.2 | 65.7 |
| Mandel | 485.4 | 0 | 480.4 | 465.9 | 36.04 |
Here’s a supplement from tests I did with a 5900x in a similar environment.
| Test Item | windows | ESXi | PVE |
|---|---|---|---|
| cpuz-Single | 631.5 | 637.4 | 635.1 |
| cpuz-Multi | 8995.9 | 9210.3 | 9203.7 |
| MEM-Read | 46346 | 43237 | 45939 |
| MEM-Write | 46351 | 40004 | 45275 |
| MEM-Copy | 45266 | 42283 | 44383 |
| MEM-Latency | 79.1 | 80.7 | 60.9 |
| Single Float | 1315 | 1606 | 1631 |
| Double Float | 825.6 | 798 | 810.9 |
| 24bit Int | 1315 | 1286 | 1303 |
| 32bit Int | 1307 | 1280 | 1298 |
| 64bit Int | 105.7 | 104.8 | 106 |
| AES-256 | 201179 | 136510 | 92500 |
| SHA-1 | 47263 | 42123 | 36948 |
| Julia | 707.1 | 533.3 | 543.5 |
| Mandel | 386.9 | 289.5 | 299.3 |
MEM
The scores come from AIDA64, and I set the timings loosely. The unit for the first item is GiB/S, and the second item is MiB/S, which are actually quite similar.
-
When using big and little cores, PVE is incompatible with AIDA64. It should not be counted in the scores.
| Test Item | windows | Hyper-V | Workstation | ESXi | PVE |
|---|---|---|---|---|---|
| MEM-Read | 105.40 | 102.91 | 103.44 | 100.47 | 8124 |
| MEM-Write | 90843 | 91450 | 91111 | 89628 | 6798 |
| MEM-Copy | 93650 | 89807 | 91215 | 96925 | 7062 |
| MEM-Latency | 70.3 | 86.9 | 75.1 | 76.9 | 781.5 |
DISK
Testing was conducted using Crystal Disk Mark 8.0.4, with default test items. The parameters were set to 64GiB, 5.
Only VMware Workstation, which is a fully virtualized VM, cannot fully utilize performance. Note: Do not use old and inferior SATA and SCSI controllers, as their performance is poor.
-
The incredible 4k read of VMware Workstation should be due to memory acceleration being enabled.
| Test Item | windows | Hyper-V | Workstation | ESXi | PVE |
|---|---|---|---|---|---|
| SEQ1M-Q8T1-Read | 6309.68 | 6316.14 | 4681.29 | 6800.49 | 6641.09 |
| SEQ1M-Q8T1-Write | 4057.99 | 4060.33 | 2557.69 | 4147.90 | 4141.40 |
| SEQ1M-Q1T1-Read | 3354.80 | 3113.56 | 2751.92 | 3244.73 | 3245.54 |
| SEQ1M-Q1T1-Write | 3663.85 | 3380.36 | 2478.29 | 3351.48 | 3393.28 |
| RND4k-Q32T1-Read | 1521.80 | 725.47 | 422.60 | 501.97 | 819.89 |
| RND4k-Q32T1-Write | 1292.43 | 741.58 | 291.87 | 902.25 | 605.58 |
| RND4k-Q1T1-Read | 57.29 | 43.18 | 74.42 | 39.69 | 45.17 |
| RND4k-Q1T1-Write | 312.17 | 99.16 | 66.70 | 85.72 | 116.78 |
NET
The test items involve reading between virtual machines through a memory bridge, and the speed of local loopback tested directly on bare metal.
This test seems to have significant fluctuations in results, so it is for reference only. Anyway, Workstation is just getting beaten.
| Test Item | windows | Hyper-V | Workstation | ESXi | PVE |
|---|---|---|---|---|---|
| Iperf3-T1 w2w | 68.8 | 22.0 | 6.53 | 13.1 | 23.8 |
| Iperf3-T32 w2w | 125 | 35.9 | 6.58 | 50.6 | 42.9 |
| Iperf3-T32 l2w | 31.3 | 6.27 | 50.9 | 43.7 |
