Home WiFi Networking Solutions: Wired Mesh vs AC+AP

In this era of interconnected devices, a stable and fast home WiFi network has become a necessity. As homes grow larger, a single router often fails to meet the need for full coverage. Currently, there are two mainstream whole-home WiFi solutions on the market: wired mesh and AC+AP. Today, we will delve into the advantages and disadvantages of these two solutions to help you make the most suitable choice for yourself.

1. Solution Principle Analysis

Wired Mesh Solution

A wired mesh refers to connecting multiple mesh routers via Ethernet cables to form a unified network. Each mesh node has complete routing capabilities, allowing for flexible networking and automatic roaming. Data is transmitted between mesh nodes through wired backhaul, avoiding performance loss caused by wireless backhaul.

AC+AP Solution

AC+AP is a combination of “Access Controller (AC) + Access Point (AP)”. The AC manages and controls the entire network, while the AP is responsible for wireless signal coverage. All APs are managed centrally by the AC, enabling zero-configuration auto-setup and centralized management.

2. Advantages and Disadvantages Comparison

Wired Mesh Advantages:

1. 1. Simple Deployment: Plug and play, no complex configuration required. Mesh nodes automatically discover and network themselves, requiring low network knowledge.
2. 2. Complete Functionality: Each mesh node is an independent router with full functionality, including parental controls, QoS, etc. Even if the main node fails, other nodes can still operate normally.
3. 3. Flexible Expansion: Mesh nodes can be added or removed at any time, allowing the network to expand flexibly based on needs.

Wired Mesh Disadvantages:

1. 1. Higher Cost: Each mesh node is a complete router, and hardware costs are higher than ordinary APs.
2. 2. Redundant Functionality: All nodes have complete routing capabilities, leading to some resource wastage.

AC+AP Advantages:

1. 1. Cost-Effective: APs only handle wireless access, resulting in lower hardware costs, suitable for large-scale deployment.
2. 2. Centralized Management: All APs are managed centrally by the AC, facilitating operation and maintenance as well as troubleshooting.
3. 3. Professional Functionality: Supports enterprise-level features such as RF optimization and load balancing.

AC+AP Disadvantages:

1. 1. Complex Deployment: Requires professional network knowledge, with a higher configuration threshold.
2. 2. Dependent on AC: If the AC fails, the entire network will be unable to function normally.

3. Applicable Scenarios Analysis

Wired Mesh is Suitable for:

1. 1. Home Users: Easy to operate, sufficient functionality, and a good choice for families with enough budget.
2. 2. Small Offices: Small office environments with fewer than 10 people, where network management requirements are not high.
3. 3. Temporary Networking: Quick deployment of wireless networks in temporary situations such as exhibitions or roadshows.

AC+AP is Suitable for:

1. 1. Large Venues: Scenarios like schools and shopping malls that require the deployment of numerous APs.
2. 2. Enterprise Offices: Medium to large enterprises that require professional network management features.
3. 3. Tech Enthusiasts: Users who understand network technology and enjoy DIY.

4. Purchasing Suggestions

Wired Mesh Purchasing Points:

1. 1. Prefer products that support wired backhaul.
2. 2. Pay attention to the hardware configuration of individual nodes.
3. 3. Check if it supports 160MHz bandwidth.
4. 4. Verify if the app features meet your needs.

AC+AP Purchasing Points:

1. 1. The AC performance should meet the AP quantity requirements.
2. 2. APs should support PoE power supply.
3. 3. Confirm the compatibility between AC and AP.
4. 4. Check if roaming functionality is supported.

5. Conclusion

If you are an ordinary home user seeking simplicity and ease of use, it is recommended to choose the wired mesh solution. If you are an enterprise user or a network enthusiast needing professional management features, the AC+AP solution may be more suitable. Regardless of which solution you choose, ensure that all nodes use wired connections to achieve the best network experience.

Remember, there is no best solution, only the most suitable one. Making a choice based on your actual needs and budget is the right approach.
