Robot GPU Board PCBA Partial display (chips have been masked, PCBA has been partially masked)
Robot GPU Board Inner layer circuit partial display
Robot GPU Board duplication delivery content:
Our duplication capabilities:
Duplication Board types:
Rigid boards, flexible boards, HDI boards, ultra-high frequency boards(above 100HZ), ceramic boards, aluminum substrate, etc.
Duplication product types:
Communication products Medical products High-power power supply products Consumer security products Power electronic devices, etc.
Duplication Layers:2-32 layers (including first-order, second-order, third-order, and other high-precision multilayer boards)
Maximum board thickness: 6mm
Precision Control: +-0.05mm
Maximum size: 640mmx480mm
Precision Control: +-0.1mm
Minimum line width:3mil
Minimum via:3mil
Impedance calculation:5～150 Ω
Our duplication advantages:
1. High quality and guaranteed:One-time cloning success, circuit accuracy guaranteed at 100%
Industry-leading PCB duplication software combined with our self-developed software plugins maximizes the accuracy of PCB duplication. We can achieve a duplication accuracy of +-0.5mil based on a complete sample (or prototype) provided by the customer. A standard duplication process, a complete quality assurance system, and advanced manufacturing and testing equipment provide excellent quality assurance.
2. Rich duplication experience:Over ten years of deep involvement in integrated circuit technology reverse analysis and PCB professional duplication
Rich practical experience in various blind and buried hole boards, laser blind hole boards, ultra-high frequency boards, ceramic boards, etc. We use the most advanced scanning technology combined with software technology to clone single and multilayer PCBs, as well as various high-difficulty blind and buried hole PCBs. For example, computer motherboards, high-end graphics card boards, gigabit network device substrates, or those with strict high-frequency processing requirements, electromagnetic compatibility, and impedance control, such as cordless phone motherboards, mobile phone motherboards, wireless network card devices, and industrial control motherboards with up to 30 layers and dense blind and buried holes, we can successfully clone based on a complete sample (or prototype) provided by the customer.
3. Short cycle High efficiency:Professional machine polishing and duplication scripts greatly improve duplication efficiency
Our multilayer board duplication uses professional machine polishing, greatly improving duplication efficiency. For urgent projects, we will assist you by prioritizing your order, working overtime, and ensuring quality while helping you meet deadlines. Our service philosophy: reduce customer costs, save customer time, and guarantee a 100% success rate.
Standard delivery documentation:
